OCPP EV Charging Solutions

Home EV Charger

Multiple Colors 7kW 11kW OCPP 1.6J & 2.0.1 WiFi & Bluetooth Mini Smart EV Charger

The smallest and most stylish EV charger for home charging, dynamic power distribution to make sure of a safe and effective network for EV chargers, solar, grid system and energy storage systems.

  • Input Rating: 1-phase 230V±20% ; 3-phase 400V±20%
  • Output Rating: 1-phase 7kW 32A ; 3-phase 11kW 16A
  • Internal RCD: AC 30mA & DC 6mA IEC62955 & IEC61008 certified
  • Network Interface: Ethernet/ WiFi/ Bluetooth smart internet connection
  • OCPP: Full OCPP 1.6J/ OCPP 2.0.1 support
  • ISO15118 Plug&Charge: Upgradable
  • Ingress Protection: IP55
  • Shipping Dimensions: 398 x 285 x 176 mm; 398 x 285 x 226 mm
  • Charging Interface: SAE J1772 & Type-2 cable/ Type-2 socket
  • Mounting Type: Wall or Floor( pedestal supplied separately)

IOCAH15 is a perfect choice for home charging with a compact design yet powerful and smart. Multiple functions are available on IOC Lite App to manage charging schedules, load balancing and energy sources from solar & battery.

Main features:

  • Compatible with all EVs and power grids
  • Single phase 32A 7kW & Three phase 16A 11kW available
  • Streamlined design, simple and elegant appearance
  • Ethernet, Wi-Fi, Bluetooth connection
  • Flexible output current / power configuration
  • Customizable breathing light according to preferences
  • Smart dynamic load balancing support
  • User authentication via Mobile App
  • Multifunctional charger commissioning web portal
  • Remote control and monitoring
  • AC 30mA & DC 6mA current leakage protection IEC62955 & IEC61008 certified

Bluetooth Technology

IOCAH15 has integrated our latest Bluetooth technology to maximize the user experience in challenging environments like underground parking, in apartment buildings and offices, our mobile App can work seamlessly with or without network connection.

Users can start, stop and manage the charger via an Internet/Bluetooth connection and the data will be synchronized between the phone and back-end once the phone has coverage.

Dynamic Load Balancing

The CT clamp can be connected to the IOCAH15 mini smart AC charger directly for current monitoring of other home appliances, without extra device. The charging current is automatically adjusted according to real-time current values. It can prevent our home from overloading with installation of single or multiple chargers, either online or offline.

OCPP 1.6J & 2.0.1

As a member of OCA(OCPP) & OCPI, our EV chargers are always integrated with the latest OCPP technology including OCPP 1.6J and OCPP 2.0.1. With more than 8 years’ OCPP experience, our chargers are certified by major OCPP platforms and CPOs.

Optimize Energy Usage

Fully compatible with solar installation and battery storage system. Connect IOCAH15 to IOC Lite Mobile App to experience Fast, ECO, ECO+ modes to minimize the charging cost, monitor and utilize different energy sources from grid, solar and home batteries.
